PresentationAPI使用教程(Vue3&html)

　W3C在2020年12月份出台了Presentation API规范，这个api接口允许用户自由控制投放在其他屏幕上，并和投放窗口通信，查看W3C规范。演示地址：投屏演示，详细demo（Vue3/HTML）见文章末尾

/*
 * @Author: lzx
 * @Date: 2022-07-08 15:34:16
 * @LastEditors: lzx
 * @LastEditTime: 2022-07-08 17:14:31
 * @Description: Fuck Bug
 * @FilePath: \test\js\index.js
 */
// 创建个投屏对象
const presentationRequest = new PresentationRequest(['https://blog.fxnws.com']); // 投屏网址
// const presentationRequest = new PresentationRequest(['test.html']);//投屏页面

// Make this presentation the default one when using the "Cast" browser menu.
navigator.presentation.defaultRequest = presentationRequest;
let presentationConnection;

//监视连接是否可用
presentationRequest.addEventListener('connectionavailable', function (event) {
  presentationConnection = event.connection;
  presentationConnection.addEventListener('close', function () {
    console.log('> Connection closed.');
  });
  presentationConnection.addEventListener('terminate', function () {
    console.log('> Connection terminated.');
  });
  presentationConnection.addEventListener('message', function (event) {
    console.log('> ' + event.data);
  });
});

//监视可用的显示器
presentationRequest.getAvailability()
  .then(availability => {
    console.log('Available presentation displays: ' + availability.value);
    availability.addEventListener('change', function () {
      console.log('> Available presentation displays: ' + availability.value);
    });
  })
  .catch(error => {
    console.log('Presentation availability not supported, ' + error.name + ': ' +
      error.message);
  });
// 开启投屏
function startProjectionScreen () {
  presentationRequest.start()
    .then(connection => {
      console.log('Connected to ' + connection.url + ', id: ' + connection.id);
    })
    .catch(error => {
      console.log(error);
    });
}

//发送消息
function sendMsg () {
  const message = '发送消息测试';
  const lang = document.body.lang || 'en-US';

  console.log('Sending "' + message + '"...');
  presentationConnection.send(JSON.stringify({ message, lang }));
}

//关闭连接，关闭连接后无法再控制弹出窗口
function closeLink () {
  console.log('Closing connection...');
  presentationConnection.close();
}
//关闭连接后，换可以重新再次连接，这里需要指定id
// presentationRequest.reconnect(presentationId);

//关闭弹窗，结束连接调用
function endLink () {
  console.log('Terminating connection...');
  presentationConnection.terminate();
}

　3、连接端页面消息的展示（搬运的官方）

/*
 * @Author: lzx
 * @Date: 2022-07-08 15:34:16
 * @LastEditors: lzx
 * @LastEditTime: 2022-07-08 15:34:30
 * @Description: Fuck Bug
 * @FilePath: \test\js\test.js
 */
let connectionIdx = 0;
let messageIdx = 0;

//如果有连接建立，则调用该函数
function addConnection (connection) {
  connection.connectionId = ++connectionIdx;
  addMessage('New connection #' + connectionIdx);
  connection.addEventListener('message', function (event) {
    messageIdx++;
    const data = JSON.parse(event.data);
    const logString = 'Message ' + messageIdx + ' from connection #' +
      connection.connectionId + ': ' + data.message;
    addMessage(logString, data.lang);
    maybeSetFruit(data.message);
    connection.send('Received message ' + messageIdx);
  });

  connection.addEventListener('close', function (event) {
    addMessage('Connection #' + connection.connectionId + ' closed, reason = ' +
      event.reason + ', message = ' + event.message);
  });
};

const fruitEmoji = {
  'grapes': '\u{1F347}',
  'watermelon': '\u{1F349}',
  'melon': '\u{1F348}',
  'tangerine': '\u{1F34A}',
  'lemon': '\u{1F34B}',
  'banana': '\u{1F34C}',
  'pineapple': '\u{1F34D}',
  'green apple': '\u{1F35F}',
  'apple': '\u{1F34E}',
  'pear': '\u{1F350}',
  'peach': '\u{1F351}',
  'cherries': '\u{1F352}',
  'strawberry': '\u{1F353}'
};

function addMessage (content, language) {
  const listItem = document.createElement("li");
  if (language) {
    listItem.lang = language;
  }
  listItem.textContent = content;
  document.querySelector("#message-list").appendChild(listItem);
};

function maybeSetFruit (message) {
  const fruit = message.toLowerCase();
  if (fruit in fruitEmoji) {
    document.querySelector('#main').textContent = fruitEmoji[fruit];
  }
};

//文档载入后，监听连接
document.addEventListener('DOMContentLoaded', function () {
  if (navigator.presentation.receiver) {
    navigator.presentation.receiver.connectionList.then(list => {
      list.connections.map(connection => addConnection(connection));
      list.addEventListener('connectionavailable', function (event) {
        addConnection(event.connection);
      });
    });
  }
});

　4、接收端页面构

<!--
 * @Author: lzx
 * @Date: 2022-07-08 15:34:05
 * @LastEditors: lzx
 * @LastEditTime: 2022-07-08 15:35:13
 * @Description: Fuck Bug
 * @FilePath: \test\test.html
-->
<!doctype html>
<html>

<head>
  <meta charset="utf-8">
  <title>Demo Receiver</title>
  <style type="text/css">
    html,
    body {
      height: 100%;
      margin: 0;
      font-family: sans-serif;
      background: radial-gradient(ellipse at center, #333333 0%, #000000 100%);
      color: #fff;
    }

    #main {
      position: absolute;
      top: 50%;
      left: 50%;
      transform: translate(-50%, -50%);
      text-align: center;
      font-size: 54px;
    }
  </style>
  <script type="text/javascript" src="引入3的代码块"></script>
</head>

<body>
  <div id="main">Hello World!</div>
  <ul id="message-list">
  </ul>
</body>

</html>

　5、vue3页面

<template>
  <div class="container">
    <button @click="startProjectionScreen">开启投屏</button>
    <button @click="sendMsg">发送消息</button>
    <!-- <button @click="closeLink">关闭连接</button> -->
    <button @click="endLink">结束调用</button>
  </div>
</template>

<script lang="ts">
// @ts-nocheck 不在当前文件中执行类型检查
import { toRefs, reactive, onMounted, watchEffect, onUnmounted } from 'vue'
export default {
  props: {},
  components: {},
  setup () {
    const presentationRequest = new PresentationRequest(['https://blog.fxnws.com']); // 投屏网址
    // const presentationRequest = new PresentationRequest(['test.html']); // 投屏本地页面
    navigator.presentation.defaultRequest = presentationRequest;
    let presentationConnection;
    // 传参
    const state = reactive({
    })
    const startProjectionScreen = () => {
      presentationRequest.start()
        .then(connection => {
          console.log('Connected to ' + connection.url + ', id: ' + connection.id);
        })
        .catch(error => {
          console.log(error);
        });
    }
    //发送消息
    const sendMsg = () => {
      const message = '发送消息测试';
      const lang = document.body.lang || 'en-US';

      console.log('Sending "' + message + '"...');
      presentationConnection.send(JSON.stringify({ message, lang }));
    }

    //关闭连接，关闭连接后无法再控制弹出窗口
    const closeLink = () => {
      console.log('Closing connection...');
      presentationConnection.close();
    }
    //关闭连接后，换可以重新再次连接，这里需要指定id
    // presentationRequest.reconnect(presentationId);

    //关闭弹窗，结束连接调用
    const endLink = () => {
      console.log('Terminating connection...');
      presentationConnection.terminate();
    }
    // 挂载
    onMounted(() => {
      //监视连接是否可用
      presentationRequest.addEventListener('connectionavailable', function (event) {
        presentationConnection = event.connection;
        presentationConnection.addEventListener('close', function () {
          console.log('> Connection closed.');
        });
        presentationConnection.addEventListener('terminate', function () {
          console.log('> Connection terminated.');
        });
        presentationConnection.addEventListener('message', function (event) {
          console.log('> ' + event.data);
        });
      });
      //监视可用的显示器
      presentationRequest.getAvailability()
        .then(availability => {
          console.log('Available presentation displays: ' + availability.value);
          availability.addEventListener('change', function () {
            console.log('> Available presentation displays: ' + availability.value);
          });
        })
        .catch(error => {
          console.log('Presentation availability not supported, ' + error.name + ': ' +
            error.message);
        });
    })
    // 监听
    watchEffect(() => {
      console.log('监听')
    })
    // 页面卸载
    onUnmounted(() => {
      console.log('页面卸载')
    })
    return {
      ...toRefs(state), endLink, closeLink, sendMsg, startProjectionScreen
    }
  }
}
</script>

<style scoped>
</style>

　6、详细demo附件下载

2024年11月04日更新，看到评论区有部分朋友，遇到问题，我更新了相关Git完整Demo地址见下文
1、vue3+ts+vite 报错 PresentationRequest 未定义
答：应该是ts未定义的报错，我当时做这个的时候，这个功能刚推出ts支持应该不完善，我也不想去定义相关的ts就直接使用// @ts-nocheck（这个指令用于告诉TypeScript编译器不在当前文件中执行类型检查）
2、发现用ip访问不行，用127.0.0.1可以
答：直接用IP不行是因为没有https支持吧，我记得这个协议是需要https的支持的，具体要看下报错信息了，127.0.0.1是本机地址所以没事
